Custormized Size and Type
SHANQI
Product Description
High quality 21mm x 21mm Plain Steel channel, steel channel profiles
Channel steel is a long strip steel with a concave section, which belongs to carbon structural steel for construction and machinery.Channel steel is mainly used in construction structure, curtain wall engineering, machinery equipment and vehicle manufacturing.widely use:Construction, curtain wall engineering, mechanical equipment and vehicle manufacturing.
| Products | U Channel Steel |
| Size | as customer's required |
| Grade | Q235B,Q345B |
| Type | GB standard(10#-40#,100*48mm--400*102mm) |
| JIS standard(50*25mm--250*90mm) | |
| Length | 6m, 12m,Large quantity can be customized |
| Technique | Hot rolled |
| Application | Mainly used for building structure, vehicle manufacturing and other industrial structure, channel steel is often used with i beam. |
| Payment Terms | L/C , T/T or Western Union |
| size | Height | leg width | waist thickness | sectional area(cm²) | weight |
| 5# | 50 | 37 | 4.5 | 6.928 | 5.438 |
| 6.3# | 63 | 40 | 4.8 | 8.451 | 6.634 |
| 6.5# | 65 | 40 | 4.3 | 6.709 | |
| 8# | 80 | 43 | 5 | 10.248 | 8.045 |
| 10# | 100 | 48 | 5.3 | 12.748 | 10.007 |
| 12# | 120 | 53 | 5.5 | 12.059 | |
| 12.6 | 126 | 53 | 5.5 | 15.692 | 12.319 |
| 14#a | 140 | 58 | 6 | 18.516 | 14.535 |
| 14#b | 140 | 60 | 8 | 21.316 | 16.733 |
| 16#a | 160 | 63 | 6.5 | 21.962 | 17.24 |
| 16#b | 160 | 65 | 8.5 | 25.162 | 19.752 |
| 18#a | 180 | 68 | 7 | 25.699 | 20.174 |
| 18#b | 180 | 70 | 9 | 29.299 | 23 |
| 20#a | 200 | 73 | 7 | 28.837 | 22.637 |
| 20#b | 200 | 75 | 9 | 32.837 | 25.777 |
| 22#a | 220 | 77 | 7 | 31.846 | 24.999 |
| 22#b | 220 | 79 | 9 | 36.246 | 28.453 |
| 25#a | 250 | 78 | 7 | 34.917 | 27.41 |
| 25#b | 250 | 80 | 9 | 39.917 | 31.335 |
| 25#c | 250 | 82 | 11 | 44.917 | 35.26 |
| 28#a | 280 | 82 | 7.5 | 40.034 | 31.427 |
| 28#b | 280 | 84 | 9.5 | 45.634 | 35.832 |
| 28#c | 280 | 86 | 11.5 | 51.234 | 40.219 |
| 30#a | 300 | 85 | 7.5 | 34.463 | |
| 30#b | 300 | 87 | 9.5 | 39.173 | |
| 30#c | 300 | 89 | 11.5 | 43.883 | |
| 32#a | 320 | ৪৪ | 8 | 48.513 | 38.083 |
| 32#b | 320 | 90 | 10 | 54.913 | 43.107 |
| 32#c | 320 | 92 | 12 | 61.313 | 48.131 |
| 36#a | 360 | 96 | 9 | 60.91 | 47.814 |
| 36#b | 360 | 98 | 11 | 68.11 | 53.466 |
| 36#c | 360 | 100 | 13 | 75.31 | 59.118 |
| 40#a | 400 | 100 | 10.5 | 75.068 | 58.928 |
| 40#b | 400 | 102 | 12.5 | 83.068 | 65.208 |
| 40#c | 400 | 104 | 14.5 | 91.068 | 71.488 |
FAQ：
Q: What kind of work does your company do?
A: We are a business steel industry and trade.
We mainly produces galvanized steel plate/pipe/coil/round bars, etc.
Q: What are the advantages of your company?
A: (1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Samples can be provided as your requirements.
Q: What is your terms of payment ?
A: Can be negotiated by both parties. If you have another question, pls feel free to contact us as below.
Q: What about your price?
A: Our price is very competitive.
Pls feel free to contact us if you are interested in our products.
Q: How long is your delivery time?
A: Different products have different delivery time. The products will be delivered as soon as possible on the basis of the quality assurance. Usually the delivery time is within5-15 days after we received your balance.
