Product Description
1. Types of marine steel
Marine steel can generally be divided into steel for hull structure and steel for boiler, pressure vessel and mechanical structure.
(1) General strength hull structural steel is the former marine carbon steel, which is divided into four grades: A, B, D, and E. Grade A is boiling steel, B satin is killed steel, grade D and E are fully killed fine grain (aluminum treatment) steel, the manganese content in grade E steel is higher than that of D grade steel and the carbon content is lower than D grade steel steel.
At present, general-strength hull structural steel is widely used in the welding of small and medium-sized ships.
(2) High-strength hull structural steel is also called marine low-alloy steel.
Since high-strength hull structural steel is smelted by adding a small amount of alloying elements such as manganese, niobium, vanadium, aluminum and silicon on the basis of general-strength hull structural steel, its strength, mechanical properties, weldability, corrosion resistance and The ancient items such as wear resistance are better than general strength hull structural steel. Although the price of steel itself is expensive, because of the above-mentioned properties, the amount of steel used in shipbuilding can be reduced, thereby reducing the weight of the hull structure and reducing the cost of shipbuilding. The final economic index is similar to that of general-strength hull structural steel .
2. Application types of marine steel
In order to meet the different needs of the structure of each part of the hull, there are mainly the following types of marine steel in practical application:
(1) Steel plate
Steel plates are the main components of the hull structure, accounting for about 60%-65%, such as hull plates, deck plates and partitions. Generally, steel plates with a thickness of 4mm or less are called thin plates, and those with a thickness of 4mm or more are called thick plates. The size range of marine steel plates is generally: thickness 6-40mm, width 1 200b3 000rDATI, length 6000, 14000mm.
(2) Section steel
The proportion of standard steel section in the hull structure is second only to the steel plate, about 35%-40%, and is mainly used as the hull skeleton. According to its cross-sectional shape, it can be divided into: flat steel, spherical flat steel, angle steel, I-beam, T-shaped steel and channel steel, etc.
(3) Cast steel and forged steel
Fore and stern posts, anchors, fairleads, bollards and stern tubes of ships are often made of cast steel, while simple-shaped components such as rudder stock and shafts of ships are mostly made of forged steel.
Product Specification
Product name | Marine Steel Plate |
Thickness/width/length | As you require |
Technique | Hot rolled |
Surface | Clean, blasting and painting according to customer requirement. |
Some steel plates in stock | CCS DH36 Marine Steel Plate CCS AH36 Marine Steel Plate ASTM A131 Grade A/B Marine Steel plate ABS Grade EH32 Shipbuilding Steel Plate LR Grade EH40 Marine Steel Plate CCS AH40 DH40 EH40 FH40 Marine Steel Plate CCS FH40 Marine Steel Plate SA662 GR.B Moderate and lower temperature Pressure Vessel Steel plate CCS EH40 Marine Steel Plate CCS DH40 Marine Steel Plate A285 GR.C Pressure vessel steel plate CCS AH40 Marine Steel Plate RINA Grade FH40 Marine Steel Plate RINA Grade EH40 Marine Steel Plate ASTM A285 Grade A Boiler steel plate RINA Grade AH36 DH36 EH36 FH36 Marine Steel Plate RINA Grade AH40 Marine Steel Plate SA387 GR.21 CL1 Pressure vessel steel plate A537 CLASS 2 Heat treated Boiler steel plate, etc. |
| Payment Terms | T/T, L/C |
| Packing | Standard export packing (inside:water proof paper,outside:steel covered with strips and pallets) |
