Product Description
Hot Rolled Steel Sheet are steel sheet that has been cut from Hot Rolled Steel Coil to the specific dimensions. It is similar to other hot rolled steel products in the sense that they are used in constructions, engineering, the automotive industry to produce consumer goods. Generally, it has a smooth surface and comes in standard or customized dimension as well as wide range of thickness to support various construction works. Some of the common grades includes SS400, SS490, and SM400.
It is widely used in manufacturing casings, element/parts of tools machinery, guard rails and automotive body parts. As for other customize uses would involved process such as Drawing and Stamping.
| SPECIFICATIONS FOR Wear Resistant Steel Plate/Sheet | |||
| Product Name | Hot Rolled Wear Steel AR400 AR500 NM400 NM500 Wearing Resistant Steel Plate | ||
| Standard | AISI,ASTM, EN, BS, GB, DIN, JIS | ||
| Materials | NM360,NM360L,NM400,NM400L,NM400A,NM450,NM450L,NM450A,NM500A.NM550,NM600. NR360,NR400,MITTA 400F,MITTA 450F,MITTA 500F DILLIDUR400,DILLIDUR500,DILLIDUR400V,DILLIDUR500V,DILLIDUR450V QUARD400,QUARD450,QUARD500 FORA400,FORA500,CREUSABRO4800,CREUSABRO8000 RAEX400,RAEX450,RAEX500 | ||
| Inspection | ISO, CE, etc. | ||
| Packing | Waterproof paper, and steel strip packed. Standard Export Seaworthy Package. Suit for all kinds of transport, or as required. | ||
| Supply Ability | 500000 tons/Year | ||
| MOQ | 5 ton, sample order accepted. | ||
| Shipment time | Within 7-15 workdays after receiving deposit or L/C | ||
| Chemical Content | ||||||||
| Steel/Grade | C | Si | Mn | P | S | AL | Cr+Ni+Mo | Nb+V+Ti |
| NM360/AR360 | 0.10-0.30 | 0.20-0.40 | 1.00-2.00 | ≤0.015 | ≤0.003 | ≥0.20 | <0.6 | Trace Amount |
| NM400/AR400 | 0.10-0.40 | 0.20-0.40 | 1.00-2.00 | ≤0.015 | ≤0.003 | ≥0.20 | <0.9 | |
| NM450/AR450 | 0.10-0.40 | 0.20-0.40 | 1.00-2.00 | ≤0.015 | ≤0.003 | ≥0.20 | <1.2 | |
| NM500/AR500 | 0.10-0.40 | 0.20-0.45 | 1.00-2.00 | ≤0.015 | ≤0.003 | ≥0.20 | <1.5 | |
| NM550/AR550 | 0.10-0.50 | 0.20-0.45 | 1.00-1.50 | ≤0.015 | ≤0.003 | ≥0.20 | <2.0 | |
| NM600/AR600 | 0.10-0.50 | 0.20-0.45 | 1.00-1.50 | ≤0.015 | ≤0.003 | ≥0.20 | <2.5 | |
| Mechanical Property | ||||
| Grade | Tensile strength | Elongation | Hardness | -20℃ Impact energy |
| (Mpa) | (%)(min) | (HBW) | AKv/J (min) | |
| NM360 | ≥1100 | 12 | 330-390 | 24 |
| NM400 | ≥1200 | 10 | 370-430 | 24 |
| NM450 | ≥1250 | 7 | 420-480 | 24 |
Wear resistant steel with 2 to 12mm in thickness are produced from processes of hot rolling, cutting into length and heat treating. The products are characterized with small thickness, good flatness, outstanding wear resistance, excellent toughness, good weldability, good machinablility, consistent property and quality. Wear resistant steels are developed for applications where high wear resistant performance is required, such as dumper, garbage vehicle, concrete mixer truck, industrial air fan, hopper, crusher, machinery for coal, grain, cement, grab bucket, etc.
Engineering machinery and equipment: loaders, bulldozers, excavators
Handling machinery and equipment: unloading mill chain plate, hopper liner, grab the edge plate, and automatic tipper tipping plate of construction machinery equipment: Cement pusher plate, concrete mixer liner, mixing building lining board.
Dust collector liner metallurgical machinery equipment: iron ore sintering conveying elbow, iron ore sintering machine liner, scraper machine liner
Mining machinery and equipment: aggregate, stone crusher liner, blade
Thermal power equipment: coal mill lining board Coal, coal conveying pipe, coal distributor frame, unloading equipment lining plate
Shot blasting machinery: shot blasting machine lining board.
Other mechanical equipment: sand barrel, blade, a variety of port machinery wear part, etc.
