Product Description
Common Specifications and Advantages of Linear Steel Sheet Pile
Another form of linear steel sheet pile, because of its low height, is close to a straight line, so it is more suitable for excavating some ditches, especially when the space between two buildings is not large and it is necessary to excavate.
Advantages of straight steel sheet piles:
1. A stable steel sheet pile wall can be formed, so as to ensure smooth downward excavation, without being affected by stepping on both sides and groundwater.
2. It also helps to stabilize the foundation, thereby ensuring the stability of the buildings on both sides
| Common Specifications of Linear Steel Sheet Pile | ||||||||
| Type | Widthmm | Highmm | Thicknessmm | Cross-sectional areacm2/m | weight | moment of inertiacm4/m | Section moduluscm3/m | |
| Single weight per pilekg/m | wall per meterkg/m2 | |||||||
| WRX 600-10 | 600 | 60 | 10.0 | 144.8 | 68.2 | 113.6 | 396 | 132 |
| WRX 600-11 | 600 | 61 | 11.0 | 158.5 | 74.7 | 124.4 | 435 | 143 |
| WRX 600-12 | 600 | 62 | 12.0 | 172.1 | 81.1 | 135.1 | 474 | 153 |
Advantages of sheet piles
1. The bearing capacity is strong, the structure is light, and the continuous wall composed of steel sheet piles has high strength and rigidity.
2. The water tightness is good, and the joints of the steel sheet piles are tightly combined, which can naturally prevent seepage.
3. The construction is simple, can adapt to different geological conditions and soil quality, can reduce the amount of earthwork for excavation of the foundation pit, and the operation takes up less space.
4. Good durability, depending on the use environment, the life span can be as long as 50 years.
5. The construction is environmentally friendly, and the amount of soil borrowed and concrete is greatly reduced, which can effectively protect land resources.
6. The operation is efficient, and it is very suitable for the rapid implementation of disaster relief and prevention such as flood control, subsidence, quicksand, and earthquakes.
7. The material can be recycled and used repeatedly. In temporary projects, it can be reused 20 to 30 times.
8. Compared with other single structures, the wall is lighter and has greater adaptability to deformation, which is suitable for the prevention and treatment of various geological disasters.
FAQ：
Q: What kind of work does your company do?
A: We are a business steel industry and trade.We mainly produces carbon steel plate/pipe/coil/bars, etc.
Q: What are the advantages of your company?
A: (1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Samples can be provided as your requirements.
Q: What is your terms of payment ?
A: Can be negotiated by both parties. If you have another question, pls feel free to contact us as below.
Q: What about your price?
A: Our price is very competitive.
Pls feel free to contact us if you are interested in our products.
Q: How long is your delivery time?
A: Different products have different delivery time. The products will be delivered as soon as possible on the basis of the quality assurance. Usually the delivery time is within 5-15 days after we received your balance.
