Product Description
H-beam is an economical section and high-efficiency section with more optimized cross-sectional area distribution and more reasonable strength-to-weight ratio. The cross-section of H-beam usually includes two parts, the web plate and the flange plate, also known as the waist and the edge. Since all parts of H-beam are arranged at right angles, H-beam has the advantages of strong bending resistance, simple construction, cost saving and light weight in all directions, and has been widely used. The main materials of H-beam are Q235B, SM490, Q345, SS400, Q345B, etc.
| Material | A36、St37、S235J0、S235J2，St52，16mn，S355JOQ195,Q215,Q235B,Q345B,S235JR，S355JR，S355，SS440，SM400A，SM400B |
| Length | 6m, 9m, 12m or as customerrequirement |
| Technology | Hot rolled,welded |
| Standard: | ASTM，AISI，JIS，GB， DIN，EN |
| Surface | As your request |
| Certification: | ISO, SGS，BV |
| Application | widely used in building structure and engineering construction, such as room beam,ship beam, industrial furnace, etc. |
| Loading port | Any port in China |
| Packing | Standard export packing or as your requirement |
H-beam classification
There are many product specifications of H-beam, and the classification methods are as follows.
(1) According to the flange width of the product, it is divided into wide flange H-beam (HW), middle flange H-beam (HM) and narrow flange H-beam (HN). The flange width B of wide flange and middle flange H-section steel is greater than or equal to the web height H. The flange width B of the narrow flange H-beam is approximately equal to one-half of the web height H.
(2) According to product use, it is divided into H-shaped steel beam, H-shaped steel column, H-shaped steel pile, and extremely thick flange H-shaped steel beam. Sometimes parallel leg channels and parallel flange T-beams are also included in the scope of H-beams. Generally, the narrow flange H-beam is used as the beam material, and the wide-flange H-beam is used as the column material.
(3) According to the production method, it is divided into welded H-beam and rolled H-beam.
(4) According to the size, it is divided into large, medium and small H-beams. Usually, products with a web height H above 700mm are called large, those with a height of 300 to 700mm are called medium, and those with a height of less than 300mm are called small. By the end of 1990, the world's largest H-beam had a web height of 1200mm and a flange width of 530mm.
FAQ：
Q: What products does your company have?
A: Our company produces all kinds of carbon steel plates, carbon steel coils, carbon steel pipes, carbon steel rods, carbon steel rebars, I-beams, H-beams, flat steels, channel steels, steel sheet piles, steel strands, etc. Rich production experience, support customization.
Q: What are the advantages of your company?
A: (1): Prime quality and Competitive price.
(2): Excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Samples can be provided as your requirements.
Q: What is your terms of payment ?
A: Can be negotiated by both parties. If you have another question, pls feel free to contact us as below.
Q: How long is your delivery time?
A: Stock steel/Steel for simple cutting/Small amount of general standard steel: about 5-20 days for delivery; Custom steel/bulk steel: about 15-30 days for delivery. Contact us for specific delivery times.
