Custormized Size and Type
SHANQI
Product Description
Mild Steel Square Tube Galvanized is a square shaped tube of galvanized Mild Steel.
Hot-dip galvanizing is the process of coating iron or steel with a thin zinc layer, by passing the steel through a molten bath of zinc at a temperature of around 860 °F (460 °C). When exposed to the atmosphere, pure zinc reacts with oxygen to form zinc oxide. This further reacts with carbon dioxide to form zinc carbonate, a dull grey, fairly strong material that stops further corrosion in many circumstances, protecting the steel below from the elements.
Galvanized steel is widely used in applications where rust resistance is needed, and can be identified by the crystallization patterning on the surface (often called a “spangle”).
Common materials and chemical compositions of carbon steel welded pipes
Grade | Level | Chemical composition,% | Deoxygenation method | ||||
C | Mn | Si | S | P | |||
No greater than | |||||||
Q195 | - | 0.06~0.12 | 0.25~0.50 | 0.30 | 0.050 | 0.045 | F、b、Z |
Q215 | A | 0.09~0.15 | 0.25~0.55 | 0.30 | 0.050 | 0.045 | F、b、Z |
B | 0.045 | ||||||
Q235 | A | 0.14~0. 22 | 0.30~0.65 | 0.30 | 0.050 | 0.045 | F、b、Z |
B | 0.12~0.20 | 0.30~0.70 | 0.045 | ||||
C | ≤ 0.18 | 0.35~0.80 | 0.040 | 0.040 | Z | ||
D | ≤ 0.17 | 0.035 | 0.035 | TZ | |||
Q255 | A | 0.18~0.28 | 0.40~0.70 | 0.30 | 0.050 | 0.045 | F、b、Z |
B | 0.045 | ||||||
Q275 | - | 0.28~0.38 | 0.50~0.80 | 0.35 | 0.050 | 0.045 | b、Z |
